创建一个100%CSS的气泡,我们从下面的标记考试。

XML/HTML Code复制内容到剪贴板 <div class="speech-bubble">Hi there!</div>

接下来,应用一些基本样式。

CSS Code复制内容到剪贴板 .speech-bubble {        positionrelative;        background-color#292929;             width200px;        height150px;        line-height150px/* 垂直居中 */            colorwhite;        text-aligncenter;    }

箭头将通过after伪元素实现。

CSS Code复制内容到剪贴板 .speech-bubble:after {        content;       }    :before和:after伪元素可以用来在元素内容之前或之后插入生成内容。 接下来,只是简单复制箭头,并定位到适当的位置。我们开始通过绝对定位的内容,重置宽度和高度,并应用边界颜色。    .speech-bubble:after {      content;      positionabsolute;           width: 0;      height: 0;           border10px solid;      border-colorred green blue yellow;    }

因为我们知道我们想要向下的箭头,上面的图片表明,除了红色(或上)边境其他的都应该被省略,或者设置为透明。

CSS Code复制内容到剪贴板 .speech-bubble:after {      content;      positionabsolute;           width: 0;      height: 0;           border10px solid;      border-top-colorred;    }

当创建CSS形状是,因为我们不能使用width属性来指定箭头的宽度,而是应该使用border-width属性。在这种情况下,箭头应该更大点;所以border-width可以增加到15px。我们将箭头定位到容器的底部居中,通过利用top和left属性。

CSS Code复制内容到剪贴板 .speech-bubble:after {      content;      positionabsolute;           width: 0;      height: 0;           border15px solid;      border-top-colorred;           top: 100%;      left: 50%;    }

到这里就差不多了;最后一个步骤是更新箭头的颜色和容器的背景颜色相同。定位也需要修改,根据边界的宽度(15 px)。当我们在这里,我们还将应用一个微妙border-radius属性来使容器更像气泡。

CSS Code复制内容到剪贴板 .speech-bubble {       /* … 其他样式 */      border-radius: 10px;    }         .speech-bubble:after {      content;      positionabsolute;           width: 0;      height: 0;           border15px solid;      border-top-color#292929;           top: 100%;      left: 50%;      margin-left: -15px/* 调整边框宽度 */   }

不错,不是吗?将这代码抽象为几个可重用的类,好应用到你将来的项目。

CSS Code复制内容到剪贴板 /*      对话气泡      用法:使用.speech-bubble和.speech-bubble-DIRECTION类      <div class="speech-bubble speech-bubble-top">Hi there</div>   */        .speech-bubble {      positionrelative;      background-color#292929;           width200px;      height150px;      line-height150px/* 垂直居中 */          colorwhite;      text-aligncenter;      border-radius: 10px;           font-familysans-serif;    }         .speech-bubble:after {      content;      positionabsolute;           width: 0;      height: 0;           border15px solid;    }              /* 箭头的位置 */        .speech-bubble-top:after {      border-bottom-color#292929;           left: 50%;      bottombottom: 100%;      margin-left: -15px;      }    .speech-bubble-rightright:after {      border-left-color#292929;           left: 100%;      top: 50%;      margin-top: -15px;       }         .speech-bubble-bottombottom:after {      border-top-color#292929;           top: 100%;      left: 50%;      margin-left: -15px;      }         .speech-bubble-left:after {      border-right-color#292929;           top: 50%;      rightright: 100%;      margin-top: -15px;       }

补充:更好的垂直居中

使用line-height实现垂直居中的一个缺点是仅限于一行。当文本需要两行或两行以上时,每一行的高度将会太大。一个聪明的解决办法是设置气泡的display属性为table,和包装段落文本的display为table-cell。这就允许我们将文本设为垂直居中。

XML/HTML Code复制内容到剪贴板 <div class="speech-bubble speech-bubble-top">       <p>Text goes here.</p>   </div>

接下来,修改CSS。

CSS Code复制内容到剪贴板 .speech-bubble {     /* 其他样式 */          display: table;    }         .speech-bubble p {      displaytable-cell;      vertical-alignmiddle;    }

如果引用display: table 带来可怕的表格布局的老式回忆,别担心。这些属性是指显示一个元素的样式。
我们不局限于三角形;CSS能产生各种各样的形状,甚至心和生物危害标志!

CSS Code复制内容到剪贴板 .biohazard {      width: 0; height: 0;           border60px solid;      border-radius: 50%;           border-top-colorblack;      border-bottom-colorblack;      border-left-coloryellow;      border-right-coloryellow;    }

CSS3制作气泡对话框的实例教程
