如下图:左侧三角形

css代码如下:

CSS Code复制内容到剪贴板 #talkbubble {        margin-left:30px;       width120px;        height80px;        backgroundred;       positionrelative;       -moz-border-radius:    10px;        -webkit-border-radius: 10px;        border-radius:         10px;    }    #talkbubble:before {       content:"";       positionabsolute;       rightright: 100%;       top26px;       width: 0;       height: 0;       border-top13px solid transparent;       border-right26px solid red;       border-bottom13px solid transparent;    }

其实,本案例的精华就是三角形的绘制,那么如何绘制三角形呢?我在这里总结一下!

上三角形,上三角形,顶部是尖的,所以用border-left,border-right,和border-bottom可以实现,给bottom一个颜色,其他设置为transparent

CSS Code复制内容到剪贴板 #triangle-up {        width: 0;        height: 0;        border-left50px solid transparent;        border-right50px solid transparent;        border-bottom100px solid red;    }

同理,大家可以判断一下如下代码分别是什么样的三角形!

CSS Code复制内容到剪贴板 #triangle-down {        width: 0;        height: 0;        border-left50px solid transparent;        border-right50px solid transparent;        border-top100px solid red;    }        #triangle-left {        width: 0;        height: 0;        border-top50px solid transparent;        border-right100px solid red;        border-bottom50px solid transparent;    }        #triangle-rightright {        width: 0;        height: 0;        border-top50px solid transparent;        border-left100px solid red;        border-bottom50px solid transparent;    }        #triangle-topleft {        width: 0;        height: 0;        border-top100px solid red;         border-right100px solid transparent;              }    #triangle-topright {        width: 0;        height: 0;        border-top100px solid red;         border-left100px solid transparent;    }    #triangle-bottomleft {        width: 0;        height: 0;        border-bottom100px solid red;         border-right100px solid transparent;      }         #triangle-bottomright {        width: 0;        height: 0;        border-bottom100px solid red;         border-left100px solid transparent;    }

判断出上面代码分别代表什么三角形吗?没错,我的命名是根据三角形的方向来的。大家可以试一下。三角形会写了,那么对话框就迎刃而解了! 不管是左侧的,还是上面的,只要改变一下before伪类的定位,就可以实现了。

当然,三角形的写法是很基础的。你也可以用css绘制出五角星、六角星、多边形、爱心等等。当然有些符号是不常用的,用的最多的还是三角形。
