近日,很多浏览器按钮点击会出现以下冲击波效果,出于好奇,参考网上的资料,将这个效果研究实现下。

实现思路:

观察波由小变大,涉及的css3属性变化有width,height,left,top,opacity,首先通过伪类实现冲击波层,同时需要设置冲击波前后的中心点位置(这里涉及一点点数学知识:画图计算两个点的位置),最后设置transition-duration: 0实现瞬间变化,ps学习到用a:active可以模拟鼠标实现点击的效果

简单画下图(很菜):

实现的代码:

  <html>  <head>  <meta charset="UTF-8">  <title>实现冲击波--数学知识很重要</title>  <style>  *{  margin:0;  padding:0;  box-sizing:border-box;  }  html,body{  font-family:"微软雅黑";  }  .wave{  position:relative;  float:left;  width:50%;  height:420px;  }  .wave a{  position:absolute;  top:50%;  left:50%;  transform:translate(-50%,-50%);  display:inline-block;  width:120px;  height:50px;  /*margin-left:-60px;  margin-top:-25px;*/  line-height:50px;  text-align:center;  border-radius:5px;  color:#fff;  font-size:16px;  cursor:pointer;  /*overflow:hidden;*/    }  #wave1{  background-color:#00BFFF;  }  #wave2{  background-color:#009955;  }  #wave1 a{  background-color:burlywood;  }  #wave2 a{/*宽度不确定长度*/  width:50%;  height:50px;  background-color:cadetblue;  }  .wave a:after{  /*画图 ,假设left:0;top:0然后画出两个中心点的水平和垂直距离*/  content: "";  display: block;  position: absolute;  left: -40px;  top: -75px;  width: 200px;  height: 200px;  background: rgba(255,255,255,0.8);  border-radius: 50%;  opacity:0;  transition: all 1s;  }  .wave a:active:after{  /*位于中间即是a的中点*/  width: 0;   height: 0;   left:60px;   top: 25px;  opacity: 1;   transition-duration: 0s;  }    #wave2 a:after{  left:50%;  top:50%;  transform:translate(-50%,-50%);  }  #wave2 a:active:after{  left:50%;  top:50%;  transform:translate(-50%,-50%);  }  </style>  </head>  <body>  <!--实现冲击波按钮确定长度-->  <div class="wave" id="wave1">  <a>点我</a>  </div>  <!--实现冲击波按钮不确定长度时-->  <div class="wave" id="wave2">  <a>点我哈哈</a>  </div>  </body>  </html>

实现的效果:

github代码:实现冲击波代码

备注:2018/01/09更新了考虑按钮长度不确定的情况,同时github代码已经更新

以上就是本文的全部内容,希望对大家的学习有所帮助,也希望大家多多支持脚本之家。
