三角形

<div class="box"></div><style>.box{            width: 0;            height: 0;            border-top: 50px solid transparent;            border-bottom: 50px solid transparent;            border-left: 50px solid transparent;            border-right: 50px solid red;}</style>

平行四边形图标

<div class="box"></div><style> .box{            width: 50px;            height: 50px;            margin: 100px auto;            background-color: red;            transform: skew(-25deg);        }</style>

暂停按钮

<div class="box"></div>    <style>        .box{            width: 50px;            height: 50px;            margin: 100px auto;            color: #000;            border: 1px solid;            border-radius: 50%;            outline: 10px solid;            outline-offset: -26px;        }    </style>

暂停按钮的实现原理就是边框用border,里面的正方形用outline。因为outline有一个offset属性可以用来设置偏移量,并且是按照比例来的。

其实如果再将outline-offset的值设置小一点,一个加好就出来了

加号

<div class="box"></div><style>    .box{        width: 50px;        height: 50px;        margin: 100px auto;        color: #000;        border: 1px solid;        border-radius: 50%;        outline: 10px solid;        outline-offset: -35px;    }</style>

如果再将其旋转,就变成了一个关闭按钮

关闭按钮

<div class="box"></div><style>    .box{        width: 50px;        height: 50px;        margin: 100px auto;        color: #000;        border: 1px solid;        border-radius: 50%;        outline: 10px solid;        outline-offset: -35px;        transform: rotate(45deg);    }

汉堡按钮

<div class="box"></div><style>    .box{        width: 50px;        height: 0px;        margin: 100px auto;        box-shadow: 36px 10px 0 3px red,        36px 0 0 3px red,        36px 20px 0 3px red;    }</style>

汉堡按钮2:

<div class="box"></div><style>    .box{        width: 30px;        height: 3px;        margin: 100px auto;        padding: 2px 0;        border-top: 3px solid red;        border-bottom: 3px solid red;        background-clip: content-box;        background-color: red;    }</style>

单选按钮

因为box-shadow会按比例缩放,因此将第一个值设置为白色,然后将第二个值设置的比第一个值大就可以了

<div class="box"></div><style>    .box{        width: 30px;        height: 30px;        margin: 100px auto;        background-color: #000;        border-radius: 50%;        box-shadow: 0 0 0 5px #fff,0 0 0 10px #000;    }</style>

圆圈中带个十字

<div class="box"></div><style>    .box {        width: 30px;        height: 30px;        margin: 100px auto;        background-color: #000;        border-radius: 50%;        box-shadow: 0 0 0 5px #fff, 0 0 0 10px #000;        outline: 36px solid #fff;        outline-offset: -50px;    }</style>

田型图标

<div class="box"></div><style>    .box {        width: 0;        margin: 100px auto;        border: 3px solid red;        outline: 6px dotted red;        outline-offset: 6px;    }</style>

下载箭头

使用border制作三角形,使用box-shadow制作正方形,主要用了偏移

<div class="box"></div><style>    .box {        width: 0;        margin: 100px auto;        color: red;        border: 8px solid transparent;        border-top: 8px solid red;        box-shadow: 0 -12px 0 -4px;    }</style>

书签

实现这种效果的原理就是讲三角形设置成背景色,这样空心的三角形就出现了

<div class="box"></div><style>    .box {        width: 0;        height: 8px;        background-color:orange;        border: 8px solid transparent;        border-bottom: 8px solid #fff;    }</style>

两个半圆图标

这个比较简单,就是通过渐变函数来实现,然后来个圆角边框

<div class="box"></div><style>    .box {       width: 50px;        height: 50px;        border-radius: 50%;        background-image: linear-gradient(to right,#ccc 50%,#000 50%);    }</style>

禁用图标

外圈利用圆角边框,里面的竖线用渐变来做,然后再用旋转属性即可

<div class="box"></div><style>    .box {       width: 50px;        height: 50px;        border-radius: 50%;        border:2px solid #000;        background: linear-gradient(to right,#fff  45%,#000 45%,#000 45%,#fff 55%);        transform: rotate(40deg);    }</style>

左右箭头图标

既然能做出一个三角形,那么就可以做出两个三角形。

<div class="box"></div><style>    .box {        width: 0;        height: 0;        margin: 100px auto;        border: 10px solid transparent;        border-left: 10px solid red;        -webkit-box-reflect: left 5px;        box-reflect:left 5px;    }</style>

需要在Chrome浏览器中打开,因为其他浏览器或许不支持

鹰嘴图标

<div class="box"></div><style>    .box {       width: 32px;        margin: 100px auto;        border-top: 50px solid transparent;        border-right: 22px solid #096;        border-bottom-right-radius: 100%;;    }</style>

 以上就是本文的全部内容,希望对大家的学习有所帮助,也希望大家多多支持脚本之家。
