有了之前的两章,小伙伴们对按钮悬浮动画是否又有了新的认识呢?

前面两章主要是从背景着手,而本章主要是围绕边框动画做效果。并且,本章节(按钮组:有趣的CSS按钮动画,带你进入CSS世界)也就到此结束了,本章结尾会对前3小节进行一定的总结。

下面继续本小节的主题,请先看一下效果示例:

看过前两小节的小伙伴,可能不需要看下面的源码,就知道如何实现了,大家可以先自己动手试试,然后再回头来看看。或许实现方式不一样,但只要能实现,都是好方法。

下面对示例讲解

示例一

<button class="btn-1">按钮一</button><style>button{  position: relative;  width: 100px;  height: 40px;  background: none;  cursor: pointer;  color: #fff;  border: none;  margin-right: 20px;  margin-bottom: 20px;}button:before, button:after{  position: absolute;  content: ;  width: 100%;  height: 100%;  z-index: 10;  transition: all .5s;}/* 按钮一 */.btn-1:before, .btn-1:after{  height: 2px;  left: 50%;  width: 0;  background: #f13f84;  transform: translateX(-50%);}.btn-1:before{  top: 0;}.btn-1:after{  bottom: 0;}.btn-1:hover:before, .btn-1:hover:after{  width: 100%;}</style>

解析:

1、 :before top为0, :after bottom为0,高度 height: 2px ,而宽度为0,并且水平居中

2、在绝对定位的作用下, :hover 改变 :before:after 的宽度,即可形成上图效果

示例二

<button class="btn-2">按钮二</button><style>.../* 这里省略上方的公共样式 */.btn-2{  background: #333;  height: 36px;}.btn-2:before, .btn-2:after{  width: 10px;  height: 10px;  background: #f13f84;  mix-blend-mode: hue;}.btn-2:before {  left: -2px;  top: -2px;}.btn-2:after {  right: -2px;  bottom: -2px;}.btn-2:hover:before, .btn-2:hover:after{  height: calc(100% + 4px);  width: calc(100% + 4px);}</style>

解析:

1、 :before:after ,超出button 2px

2、 :hover 时改变 :before:after 宽高,这里宽高用到了 calc()

calc() 函数用于动态计算长度值。

● 需要注意的是,运算符前后都需要保留一个空格,例如: width: calc(100% - 10px)

● 任何长度值都可以使用 calc() 函数进行计算;

calc() 函数支持 "+", "-", "*", "/" 运算;

calc() 函数使用标准的数学运算优先级规则;

3、大家应该都留意到了上图中,特意操作了一个属性 mix-blend-mode ,它在这里的作用让button的背景显示出来覆盖在 :before:after 背景色的上方。

css3 mix-blend-mode 语法

mix-blend-mode:normal | multiply | screen | overlay | darken | lighten | color-dodge | color-burn | hard-light | soft-light | difference | exclusion | hue | saturation | color | luminosity

hue 色相模式 “色相”模式只用“混合色”颜色的色相值进行着色,而使饱和度和亮度值保持不变。

这里就不具体讲述 mix-blend-mode ,希望后面能用一章来专门讲解。

示例三

<button class="btn-3">  <span>按钮三</span></button><style>.../* 这里省略上方的公共样式 */button span:before, button span:after{  position: absolute;  content: ;  width: 100%;  height: 100%;  z-index: 10;  transition: all .5s;}.btn-3{  background: #333;  height: 36px;}.btn-3:before, .btn-3:after, .btn-3 span:before, .btn-3 span:after{  width: 10px;  height: 10px;  background: #f13f84;  mix-blend-mode: hue;}.btn-3:before {  left: -2px;  top: -2px;}.btn-3:after {  right: -2px;  top: -2px;}.btn-3 span:before {  left: -2px;  bottom: -2px;}.btn-3 span:after {  right: -2px;  bottom: -2px;}.btn-3:hover:before, .btn-3:hover:after,.btn-3:hover span:before,.btn-3:hover span:after {  height: 60%;  width: 60%;}

解析:

1、示例三就是示例二的升级版,用span的伪类来完善按钮的四只角

2、 :hover 时改变四个伪类的宽高即可。

示例四

<button class="btn-4">按钮四</button><style>.../* 这里省略上方的公共样式 */.btn-4{  height: 34px;  border: 1px solid #f13f84;}.btn-4:before, .btn-4:after{  width: 10px;  height: 10px;  border-style: solid;  border-color: #f13f84;}.btn-4:before {  left: -4px;  top: -4px;  border-width: 1px 0 0 1px;}.btn-4:after {  right: -4px;  bottom: -4px;  border-width: 0 1px 1px 0;}.btn-4:hover:before, .btn-4:hover:after{  height: calc(100% + 7px);  width: calc(100% + 7px);}

解析:

1、示例四是示例二的另外一种实现方式,不过区别是按钮加了一个边框

2、 :before:after 直接设置 border ,而不是用 background 来展示对角样式。

width: 10px;height: 10px;border-style: solid;border-color: #f13f84;border-width: 1px 0 0 1px;

3、然后 :hover 时改变伪类宽高,即可

示例五

<button class="btn-5">按钮五</button><style>.../* 这里省略上方的公共样式 */.btn-5{  background: #333;  height: 34px;  border: 1px solid #fff;}.btn-5:before, .btn-5:after{  width: 10px;  height: 10px;  border-style: solid;  border-color: #fff;}.btn-5:before {  left: -4px;  top: -4px;  border-width: 1px 0 0 1px;}.btn-5:after {  right: -4px;  bottom: -4px;  border-width: 0 1px 1px 0;}.btn-5:hover{  border-color: #f13f84;}.btn-5:hover:before, .btn-5:hover:after{  height: calc(100% + 7px);  width: calc(100% + 7px);  border-color: #f13f84;  transform: rotateY(180deg);}

解析:

1、示例五,与示例四只有2点区别, :hover 时,使其伪类旋转180°,同时改变边框颜色

border-color: #f13f84;transform: rotateY(180deg);

示例六

<button class="btn-6">  <span>按钮六</span></button><style>.../* 这里省略上方的公共样式 */.btn-6{  overflow: hidden;}.btn-6:before, .btn-6:after, .btn-6 span:before, .btn-6 span:after{  background: linear-gradient(to right, rgba(0,0,0,0), #f13f84);  transition: all 2s;}.btn-6:before, .btn-6:after{  width: 100%;  height: 1px;}.btn-6:before {  top: 0;  left: -100%;}.btn-6:after {  bottom: 0;  right: -100%;}.btn-6 span:before, .btn-6 span:after{  width: 1px;  height: 100%;}.btn-6 span:before {  bottom: -100%;  left: 0;}.btn-6 span:after {  top: -100%;  right: 0;}.btn-6:hover:before{  animation: topA 1s linear infinite;  animation-delay: .5s;}@keyframes topA{  100%{    left: 100%;  }}.btn-6:hover span:after{  animation: rightA 1s linear infinite;  animation-delay: 1s;}@keyframes rightA{  100%{    top: 100%;  }}.btn-6:hover:after{  animation: bottomA 1s linear infinite;  animation-delay: 1.5s;}@keyframes bottomA{  100%{    right: 100%;  }}.btn-6:hover span:before {  animation: leftA 1s linear infinite;  animation-delay: 2s;}@keyframes leftA{  100%{    bottom: 100%;  }}

解析:

1、示例六,可以说和示例三有一点点相似之处吧,升级版

2、也是通过四个伪类,分别分布在按钮的上右下左位置,上下的伪类高度是1px,宽是100%,左右的伪类宽度是1px,高是100%,同时设置背景为线性渐变 linear-gradient

3、 :hover 时,上方伪类从左边-100%的位置,向左边100%的位置运动;右边伪类从上方-100%的位置,向上方100%的位置运动;下发伪类从右边-100%的位置,向右边100%的位置运动;左边伪类从下方-100%的位置,向下方100%的位置运动。然后设置延时执行动画,即可。

需要注意的是延时执行动画(animation-delay)时间,一定要调整好,否则看起来就没有流畅,衔接会出现问题。

示例七

<button class="btn-7">  <svg height="100%" width="100%" xmlns="http://www.w3.org/2000/svg">    <rect class="outline" height="100%" width="100%" />    <div class="text">按钮七</div>  </svg></button><style>.../* 这里省略上方的公共样式 */.btn-7{  position: relative;  color: #f13f84;  text-decoration: none;  width: 250px;  height: 50px;  margin: 50px auto;  overflow: hidden;}.btn-7 .outline {  position: absolute;  top: 0;  left: 0;  width: 100%;  height: 100%;  stroke: #f13f84;  stroke-width: 2px;  fill: transparent;  stroke-dasharray: 100 500;  stroke-dashoffset: 225;  transition: all .5s;  box-sizing: border-box;}.btn-7 .text {  position: relative;  top: -35px;  line-height: 1;  letter-spacing: 1px;  text-transform: uppercase;}.btn-7:hover .outline{  stroke-dasharray: 600 0;  stroke-dashoffset: 475;}

解析:

1、示例七,是一种全选的方式,svg

2、svg 元素描述

<text> 元素用于定义文本

<rect> 定义为矩形形状(圆形 <circle> 、椭圆 <ellipse> 、线 <line> 、折线 <polyline> 、多边形 <polygon> 、路径 <path>

3、svg 属性描述

stroke 定义一条线,文本或元素轮廓颜色

stroke-width 属性定义了一条线,文本或元素轮廓厚度

stroke-dasharray 属性用来设置描边的点划线的图案范式。就是设置实线和虚线的宽度。即有或者没有线段的长度。

stroke-dashoffset 则指定了dash模式到路径开始的距离

具体,后面也提供专门章节讲述

本章节(按钮组:有趣的CSS按钮动画,带你进入CSS世界)到此就结束了,首先谢谢大家的支持。

通过本章节,小伙伴们都学到了什么?

1、思想,每个小节,示例都是从易至难,循序渐进;

2、CSS 伪类元素 :before:after 的运用

3、html元素的布局,元素水平垂直居中

4、 transitionanimation 动画,它们有什么区别呢(想知道答案的可以看小编历史文章)?

5、CSS3 线性渐变和径向渐变

6、相对定位和绝对定位灵活运用

7、 transform 元素移动、变形、旋转等

到此这篇关于纯CSS3实现鼠标滑过按钮动画第二节的文章就介绍到这了,更多相关css3 鼠标滑过按钮动画内容请搜索脚本之家以前的文章或继续浏览下面的相关文章,希望大家以后多多支持脚本之家!
